92046-4-BLK TRX-4 Ford F-150 High Trail Edition

Out of stock
SKU: 92046-4-BLK Barcode: 020334392046
$ 549.95

Share to

TRX-4 Ford F-150 High Trail Edition

  • Officially Licensed1979 Ford F-150 Ranger XLT Body
    • Scale details: grille, chrome bumpers, side mirrors, door handles, and wipers
    • LED-ready headlights, tail lights, and roll bar
    • Authentic decal sheet
    • Full Nylon composite wheel wells and floor pans
  • Clipless Body mounting
    • Clipless design for smooth body appearance
    • Rugged internal body cage for added rigidity
      • Body details mount directly to internal frame
  • Trail-tuned XL-5™ HV Waterproof Electronic Speed Control
    • Fully waterproof design
    • Five drive profiles
      • Sport Mode — forward / brake / reverse
      • Race Mode — forward / brake / no reverse
      • Training Mode™ - 50% forward / 100% brake / 50% reverse (patented)
      • Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral
      • Crawl Mode — forward / instant reverse - no neutral with 100% hill holding brake
    • Traxxas EZ-Set® one-button setup
    • Large, efficient heat sink
    • Wide voltage latitude 6–7 cell NiMH (7.2–8.4V) and 2–3S LiPo (7.4–11.1V)
    • Two stage low voltage protection (LVD)
  • Titan 550 Motor
    • Powerful Titan™ 21T reverse rotation motor with internal cooling fan
    • Precision, preset gear mesh adjustments
    • Motor retention separate from gear mesh
  • Portal Axles
    • Increase ground clearance
    • Eliminate torque twist
    • Steel gears
    • Improve axle geometry and reduce strain on driveshafts
  • Drivetrain
    • Full-time shaft driven 4-wheel drive
    • Tough 6 mm stub axles
    • Steel front CV driveshafts
    • Hardened steel rear axle shafts
    • Remote locking steel gear differentials with cable-actuation
    • Steel gear transfer case
  • Factory-Installed Long Arm Lift Kit
    • Increases ground clearance over 1”
    • Maintains precise steering geometry
    • Accommodates oversize 2.2” wheels and tires
  • TQi™ 2.4 GHz Radio System
    • 4-channel transmitter
    • 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
    • Compatible with optional TQi Traxxas Link Wireless Module (6511) to access full Traxxas Link app functionality (sold separately)
    • Automatically stores and loads settings for up to 30 Traxxas Link enabled models
    • Exclusive Cruise Control feature for extended trail driving
    • Adjustable steering and throttle sensitivity (exponential)
    • Adjustable steering and throttle endpoints
    • Patented waterproof receiver box with easy-access plug
  • Extended Wheelbase
    • Long 336 mm wheelbase for improved stability
    • Full-length 1.5 mm thick steel frame rails
    • Bumpers adjust fore and aft
    • Rugged rock rails adjust for width
    • Wire routing clips integrated into frame rails
  • Innovative Battery Compartment
    • Hinged battery strap allows quick and easy battery access
    • No pins to lose
    • Accommodates different height batteries
    • Accepts full-size long battery packs
    • Integrated compartment accepts smaller 1/16 scale batteries (with optional strap)
    • Secondary front battery tray accepts smaller 1/16 scale batteries (with optional strap)
  • Transmission
    • Two speed high/low range with remote shifting
    • Dual horizontal shafts
    • Twin friction plate slipper clutch
    • Easily removed for servicing
  • Steering
    • Chassis mounted 2075X metal gear digital servo
    • Superior 45° steering angle
    • Direct steering (no servo saver)
    • Steering geometry corrected for bump steer
  • Suspension
    • Front — 3 link with panhard
    • Rear — Triangulated 4 link
    • Heavy-duty rod ends with steel hollow balls
    • 5 mm diameter steel link rods with 4 mm threaded ends
  • Extended Aluminum GTS Shocks
    • Oil-filled coilover GTS shocks exclusive to TRX-4 chassis
    • Extra-long aluminum bodies for greater articulation
    • Silver-anodized aluminum bodies
    • Threaded bodies with collars easily adjust ride height
    • Silky smooth damping for the toughest trails
    • O-ring cap seal and dual X-ring shaft seals
  • Oversize Wheels and Tires
    • 2.2” slotted mag wheels wheels with hub inserts
    • Pre-mounted 2.2” Canyon Trail tires with trail-tuned foam inserts
    • Trail tuned S1 rubber compound
    • 12 mm steel hex
  • Sealed Ball Bearings
  • Hex hardware with Rust-Resistant Black Oxide Coating
  • Requires Battery and Charger (Sold Separately)

Model Specs

Model Name: TRX-4 Ford F-150 High Trail Edition
Model Type: Trail / Crawler
Model Skill Level: 1
Scale: 1/10
Weight: 7.34 lb (3.33 kg)
Length: 22.30 inches (566 mm)
Width: 10.60 inches (270 mm)
Front Track: 10.60 inches (270 mm)
Rear Track: 10.60 inches (270 mm)
Height: 10.82 inches (275 mm)

Motor Specs

Motor Name: Titan® 550 21T reverse rotation
Motor Type: High-torque brushed motor
Motor Weight: 3.07 inches (78 mm) overall length, 2.25 inches (57 mm) can length
Motor Length: 1.53 inches (39 mm)
Motor Diameter: 3 mm
Motor Shaft Size: Bullet

ESC Specs

ESC Name: XL-5™ HV
ESC Type: Brushed
ESC Case Size: 1.23 inches (31 mm) / 2.18 inches (55 mm) / 1.04 inches (26 mm)
ESC Weight: 2.6 ounces (74 g)
Motor Connectors: Bullet
Battery Connectors: Traxxas High-Current Connector
ESC Power Wire: 14 gauge
